SurfMini - The pocket-sized Android terminal

Accept paymentson-the-go|

Our pocket-sized touch-screen terminal to support the most fast paced business needs.

Compact & Powerful

Meet SurfMini, our pocket-sized payment terminal designed for merchants who need a powerful, flexible solution for in-person payments. Whether you're a mobile business or have a POS setup on a tablet or smartphone, SurfMini offers an adaptable, affordable payment option.

Compact Design, Full Functionality: Small enough to fit in your pocket, SurfMini is designed with a 480x480px touchscreen display, offering an intuitive interface that brings the power of a full-sized terminal wherever you go.
Android 13 for Seamless Performance: SurfMini runs on Android 13, ensuring smooth, responsive interactions with the latest features and security.
Affordable and Ready to Integrate: SurfMini is great for scaling payment options for businesses in need of an external terminal.

Features Built for Modern Merchants

480x480px Touchscreen: Easy-to-read display with responsive touch for quick transactions.
Ultra-Portable: Slim, lightweight, and compact-perfect for mobile merchants.
Durable and Reliable: Engineered for all-day usage without sacrificing performance.
Versatile Integration Options: Pair easily with tablets, phones, and POS systems, making it an ideal external terminal for busy, mobile environments.

Supported Payment Methods

Here are the payment methods we support across our platform:

From registration to payments in the blink of an eye

It's very straightforward to get started. Register your developer account, get access to your keys, order terminals for your merchants, and register them upon arrival. Then you are up and ready to go.

Check out the Developer portal »

                            //Register Terminal
import axios from "axios"
const data = JSON.stringify({
    "registrationId": "250901",
    "storeId": "st_GZVDbwmS86_G9pwc669U2"
})
const response = await axios({
    url: "YOUR_API_URL/terminals",
    port: 3005,
    data,
    method: "POST",
    headers: {
        "Content-Type": "application/json",
        "API-KEY": "YOUR_API_KEY",
        "API-SECRET": "YOUR_API_SECRET"
    }
})

Specifications

CPU

MT8766

Memory

32 GB EMMC, 2 GB LPDDR4X, 128 GB Micro SD max extended storage

Operating System

Android 13 SurfOS

Main camera

2 Megapixel camera

Buttons

On/Off button

Display

3.5-inch IPS 480 x 480 px touchscreen

Sensors

G-sensor

Smart card reader

Landing type

Contactless reader

NFC-A, ISO 14443 Type A, NFC-B, ISO 14443 Type B, NFC-F, Felica, NFC-V, ISO 15693

Contactless payments

VISA payWave, MasterCard Contactless, American Express ExpressPay, Discover D-Pas

Connectors

SIM card slot, 2 x SAM card slot, USB Type-C, Contact pads

Wireless

IEEE 802.11a/b/g/n/ac

Cellular

2G/3G/4G

GNSS

GPS, A-GPS

Battery

Rechargeable Li-Po Battery, 3.85 V, 1800 mAh

Audio

Features Microphone, 0.8 W Speaker, Electromagnetic buzzer

Power supply

DC 5 V through USB, DC 5 V through contact pads

Certificates

PCI 6.x (SRED), EMV Level 1, EMV Level 2, EMV Level 1 Contactless, UN38.3

Dimensions W x D x H

78 x 15 x 89 mm

Weight

Lightweight, don't worry about it (below 150 g)

Operational temperature

-10 C to 50 C

Want to be the first with SurfMini?

Fill out the form below and we will get back to you as soon as possible.
